Lesson 7 · PictureBox

Working with PictureBox

Master image display and manipulation in Visual Basic 2026 — load images from files, control SizeMode, build an interactive photo viewer with OpenFileDialog, and create a timer-driven slideshow, with GitHub Copilot assistance throughout.

Key Takeaway: The PictureBox control displays images in JPG, PNG, BMP, GIF, TIFF, and ICO formats. Its most important property is SizeMode — it controls whether an image is cropped, stretched, zoomed, or auto-sized. In VB 2026 / .NET 10, use Async/Await with HttpClient to load images from URLs without freezing the UI, and use Image?.Dispose() (null-conditional operator) to safely free memory before loading a new image.

PictureBox — Quick Reference

🖼️ Key Properties
ImageThe image displayed
SizeModeHow image fits the control
BackColorBackground behind image
BorderStyleNone / FixedSingle / Fixed3D
VisibleShow / hide at runtime
Size / Width / HeightControl dimensions
CursorMouse cursor style on hover
ErrorImageShown if image fails to load
⚙️ Key Methods & Events
Image.FromFile()Load from disk path
Image.FromStream()Load from any stream
.Load(url)Load from URL directly
.Image = NothingClear the image
.Image?.Dispose()Free image memory safely
RotateFlip()Rotate or mirror image
.Refresh()Force repaint
Click / DoubleClickMouse click events

7.1 Understanding SizeMode

The SizeMode property is the single most important PictureBox setting. It controls what happens when the image dimensions don't match the PictureBox dimensions:

SizeModeBehaviourAspect RatioBest For
NormalNatural size, top-left. Cropped if too large.✅ PreservedSmall icons, exact-size graphics
StretchImageFills entire PictureBox by stretching.❌ DistortedBackground fills (when distortion is OK)
AutoSizePictureBox resizes to match the image.✅ PreservedFixed-size images, thumbnails
CenterImageCentred at natural size. Cropped if too large.✅ PreservedLogos, centred icons
Zoom ⭐Scales to fit, adds letterbox padding.✅ PreservedPhotos — the recommended default
Try It — Simulation 7.1: SizeMode Explorer

Click each SizeMode to see how it changes how the same image fits inside an identical 220×160 PictureBox.

SizeMode Explorer
picDisplay (220×160):
demo
SizeMode:
Normal
Image at natural size from top-left. Cropped if larger than PictureBox.
picDisplay.SizeMode = PictureBoxSizeMode.Normal

7.2 Loading an Image at Design-Time

The simplest approach is setting the image in the Properties Window — no code needed. The image gets embedded in your project's Resources and ships inside the compiled EXE.

1

Add a PictureBox

Drag a PictureBox onto the form. Set BorderStyle = FixedSingle and BackColor = Black so it has a visible frame.

2

Click the Image Property

In the Properties Window find Image and click the button. In the Select Resource dialog click Local resource → Import to browse for any image on your PC.

3

Set SizeMode = Zoom

The image appears instantly in the designer. Change SizeMode to Zoom so it fills the control proportionally without distortion.

💡 Resources vs. FromFile()

Images embedded via the Properties Window become part of Project Resources — they compile into the EXE and always exist. Image.FromFile("C:\path\photo.jpg") requires the file to exist at that exact path on every user's machine. Use Resources for logos and icons that never change; use OpenFileDialog for user-selected photos.


7.3 Loading Images at Runtime

Example 7.1 — Load from a File Path

LoadImage.vb — Visual Basic 2026
Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
    picDisplay.SizeMode = PictureBoxSizeMode.Zoom
    picDisplay.BackColor = Color.Black

    ' Load from a fixed path — file must exist
    picDisplay.Image = Image.FromFile("C:\Pictures\holiday.jpg")
End Sub
⚠ Always Handle File-Not-Found

If the path doesn't exist Image.FromFile() throws a FileNotFoundException and crashes the app. Use IO.File.Exists(path) to check first, or wrap in a Try…Catch block (covered fully in Lesson 24).

Example 7.2 — OpenFileDialog Photo Viewer

The OpenFileDialog control presents the standard Windows file browser. Drag it from the Toolbox onto the form — it lands in the component tray below (invisible at runtime).

1

Add OpenFileDialog

Drag OpenFileDialog from the Toolbox. Name it OFGSelectImage. Set its Filter to Image Files|*.jpg;*.jpeg;*.png;*.bmp;*.gif;*.webp|All Files|*.*

2

Add a PictureBox and Button

Add picDisplay (SizeMode = Zoom, BackColor = Black) and btnView (Text = "📂 Open Image"). Add lblStatus below for feedback.

3

Write the Click Handler

Double-click btnView to create its Click event, then write the code below.

PhotoViewer.vb — Visual Basic 2026
Public Class Form1

    Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
        Me.Text        = "Photo Viewer"
        picDisplay.SizeMode    = PictureBoxSizeMode.Zoom
        picDisplay.BackColor   = Color.Black
        picDisplay.BorderStyle = BorderStyle.FixedSingle
        OFGSelectImage.Filter  = "Image Files|*.jpg;*.jpeg;*.png;*.bmp;*.gif;*.webp|All Files|*.*"
        OFGSelectImage.Title   = "Select an Image"
        lblStatus.Text = "No image loaded."
    End Sub

    Private Sub btnView_Click(sender As Object, e As EventArgs) Handles btnView.Click
        If OFGSelectImage.ShowDialog() = DialogResult.OK Then

            ' Null-conditional Dispose — safe even if Image is Nothing
            picDisplay.Image?.Dispose()
            picDisplay.Image = Image.FromFile(OFGSelectImage.FileName)

            Dim img = picDisplay.Image
            Me.Text    = $"Photo Viewer — {IO.Path.GetFileName(OFGSelectImage.FileName)}"
            lblStatus.Text = $"✔  {OFGSelectImage.SafeFileName}  ({img.Width} × {img.Height} px)"
        End If
    End Sub

    Private Sub btnClear_Click(sender As Object, e As EventArgs) Handles btnClear.Click
        picDisplay.Image?.Dispose()
        picDisplay.Image = Nothing
        Me.Text        = "Photo Viewer"
        lblStatus.Text = "No image loaded."
    End Sub

End Class
Try It — Simulation 7.2: Photo Viewer with OpenFileDialog

Choose a sample image from the dropdown (simulating OpenFileDialog), adjust SizeMode, then clear.

Photo Viewer
OFGSelectImage (simulated):
SizeMode:
No image loaded
Click btnView to open
lblStatus: No image loaded.

7.4 Manipulating PictureBox at Runtime

You can change PictureBox size, visibility, and image transformation at runtime — creating interactive controls, zoom buttons, and toggle effects.

ImageEffects.vb — Visual Basic 2026
' Zoom In — grow by 24×18 px each click
Private Sub btnZoomIn_Click(sender As Object, e As EventArgs) Handles btnZoomIn.Click
    picDisplay.Width  += 24
    picDisplay.Height += 18
    lblSize.Text = $"Size: {picDisplay.Width} × {picDisplay.Height}"
End Sub

' Zoom Out — minimum 80×60
Private Sub btnZoomOut_Click(sender As Object, e As EventArgs) Handles btnZoomOut.Click
    If picDisplay.Width > 80 Then
        picDisplay.Width  -= 24
        picDisplay.Height -= 18
        lblSize.Text = $"Size: {picDisplay.Width} × {picDisplay.Height}"
    End If
End Sub

' Toggle show/hide
Private Sub btnToggle_Click(sender As Object, e As EventArgs) Handles btnToggle.Click
    picDisplay.Visible = Not picDisplay.Visible
    btnToggle.Text = If(picDisplay.Visible, "Hide", "Show")
End Sub

' Rotate 90° clockwise
Private Sub btnRotate_Click(sender As Object, e As EventArgs) Handles btnRotate.Click
    If picDisplay.Image IsNot Nothing Then
        picDisplay.Image.RotateFlip(RotateFlipType.Rotate90FlipNone)
        picDisplay.Refresh()
    End If
End Sub

' Flip horizontally
Private Sub btnFlip_Click(sender As Object, e As EventArgs) Handles btnFlip.Click
    If picDisplay.Image IsNot Nothing Then
        picDisplay.Image.RotateFlip(RotateFlipType.RotateNoneFlipX)
        picDisplay.Refresh()
    End If
End Sub
Try It — Simulation 7.3: Runtime Image Manipulation
Image Effects
demo
Size: 200 × 150 | Rotation: 0°
Click the buttons above to manipulate picDisplay at runtime.

7.5 Building an Image Slideshow with Timer

A Timer control paired with a PictureBox and an array of image paths creates an automatic slideshow. The Timer fires a Tick event at a set interval, and the handler advances the image index — wrapping back to 0 using the Mod operator.

Slideshow.vb — Visual Basic 2026
Public Class SlideShow

    Private _images() As String = {
        "C:\Photos\slide1.jpg", "C:\Photos\slide2.jpg",
        "C:\Photos\slide3.jpg", "C:\Photos\slide4.jpg"
    }
    Private _current As Integer = 0

    Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
        picSlide.SizeMode  = PictureBoxSizeMode.Zoom
        picSlide.BackColor = Color.Black
        Timer1.Interval    = 3000   ' 3 seconds
        LoadSlide(_current)
    End Sub

    Private Sub LoadSlide(index As Integer)
        picSlide.Image?.Dispose()
        picSlide.Image = Image.FromFile(_images(index))
        lblSlide.Text  = $"Slide {index + 1} of {_images.Length}"
    End Sub

    ' Tick fires every 3 s — advance and wrap around with Mod
    Private Sub Timer1_Tick(sender As Object, e As EventArgs) Handles Timer1.Tick
        _current = (_current + 1) Mod _images.Length
        LoadSlide(_current)
    End Sub

    Private Sub btnPlay_Click(sender As Object, e As EventArgs) Handles btnPlay.Click
        Timer1.Start() : btnPlay.Enabled = False : btnPause.Enabled = True
    End Sub

    Private Sub btnPause_Click(sender As Object, e As EventArgs) Handles btnPause.Click
        Timer1.Stop()  : btnPlay.Enabled = True  : btnPause.Enabled = False
    End Sub

    Private Sub btnPrev_Click(sender As Object, e As EventArgs) Handles btnPrev.Click
        _current = (_current - 1 + _images.Length) Mod _images.Length
        LoadSlide(_current)
    End Sub

    Private Sub btnNext_Click(sender As Object, e As EventArgs) Handles btnNext.Click
        _current = (_current + 1) Mod _images.Length
        LoadSlide(_current)
    End Sub

End Class
Try It — Simulation 7.4: Auto Slideshow with Timer

Press Play for the auto slideshow (3 s intervals) or use Prev/Next to browse manually.

Slideshow
Slide 1 of 4

7.6 New in VB 2026 / .NET 10 — Async URL Loading

Earlier versions required blocking WebClient calls that froze the UI. VB 2026 / .NET 10 makes this clean with Async/Await and HttpClient:

AsyncImageLoad.vb — Visual Basic 2026 / .NET 10
Imports System.Net.Http

Public Class Form1

    ' One shared instance — reused for all requests (best practice)
    Private Shared ReadOnly _http As New HttpClient()

    Private Async Sub btnLoadUrl_Click(sender As Object, e As EventArgs) Handles btnLoadUrl.Click
        Dim url = txtUrl.Text.Trim()
        If String.IsNullOrEmpty(url) Then Return

        lblStatus.Text     = "Loading…"
        btnLoadUrl.Enabled = False
        picDisplay.Image?.Dispose()
        picDisplay.Image   = Nothing

        Try
            ' Awaiting here — UI stays fully responsive during download
            Dim bytes = Await _http.GetByteArrayAsync(url)
            Dim ms    = New IO.MemoryStream(bytes)
            picDisplay.Image   = Image.FromStream(ms)
            lblStatus.Text = $"✔  {picDisplay.Image.Width} × {picDisplay.Image.Height} px"
        Catch ex As Exception
            lblStatus.Text = $"✘ Error: {ex.Message}"
        Finally
            btnLoadUrl.Enabled = True
        End Try
    End Sub

End Class
🆕 Async/Await in VB 2026

The Async keyword on a Sub/Function and Await inside it allows long operations — downloads, file reads, database queries — to run on a background thread. The UI remains fully responsive: the user can still move the window and click other buttons while the image downloads. This pattern is essential for professional VB 2026 development and is fully supported in .NET 10.


7.7 GitHub Copilot — PictureBox Assistance

GitHub Copilot — Photo Viewer Suggestion
You typed: ' Open image with OpenFileDialog, dispose old image safely, show filename and dimensions in lblStatus'
' Open image with OpenFileDialog, dispose old image safely, show filename and dimensions in lblStatus
Using dlg As New OpenFileDialog()
    dlg.Filter = "Images|*.jpg;*.jpeg;*.png;*.bmp;*.gif;*.webp|All|*.*"
    If dlg.ShowDialog() = DialogResult.OK Then
        picDisplay.Image?.Dispose()
        picDisplay.Image = Image.FromFile(dlg.FileName)
        Dim img = picDisplay.Image
        lblStatus.Text = $"{dlg.SafeFileName}  ({img.Width} × {img.Height} px)"
        Me.Text = $"Photo Viewer — {dlg.SafeFileName}"
    End If
End Using
GitHub Copilot — Slideshow Speed Control
You typed: ' Connect TrackBar1 to Timer1.Interval so speed ranges from 1s to 10s'
' Connect TrackBar1 to Timer1.Interval so speed ranges from 1s to 10s
' In Form_Load:
TrackBar1.Minimum = 1
TrackBar1.Maximum = 10
TrackBar1.Value   = 3
Timer1.Interval   = TrackBar1.Value * 1000

' TrackBar scroll event:
Private Sub TrackBar1_Scroll(sender As Object, e As EventArgs) Handles TrackBar1.Scroll
    Timer1.Interval = TrackBar1.Value * 1000
    lblSpeed.Text   = $"Speed: {TrackBar1.Value}s per slide"
End Sub
💡 Copilot Chat Prompts for This Lesson

Try these in the Copilot Chat panel while building PictureBox projects:

  • "Add a TrackBar to control PictureBox opacity from 0% to 100%"
  • "Save the current picDisplay image as PNG to the user's Pictures folder"
  • "Load all images from a folder into a FlowLayoutPanel as thumbnails"
  • "Add a fade transition between slideshow images using a Timer and opacity"

📘 Lesson Summary

  • PictureBox supports JPG, PNG, BMP, GIF, TIFF, ICO, and WEBP image formats.
  • SizeMode = Zoom is the recommended default — it scales the image proportionally without distortion. StretchImage distorts; Normal crops.
  • Embed images at design-time via the Properties Window (Image property) to compile them into the EXE as Project Resources.
  • Use Image.FromFile(path) to load at runtime — always check IO.File.Exists(path) or use Try…Catch.
  • OpenFileDialog shows the standard Windows file browser — set its Filter property to list allowed image types.
  • Always call picDisplay.Image?.Dispose() before loading a new image — the ?. null-conditional operator makes this safe even when Image is Nothing.
  • Change Width, Height, and Visible at runtime. Use RotateFlip() to rotate or mirror, followed by Refresh().
  • Combine PictureBox + Timer for a slideshow — use (index + 1) Mod count to wrap back to the first slide.
  • In VB 2026 / .NET 10, use Async/Await with HttpClient.GetByteArrayAsync() to load images from URLs without freezing the UI.

Exercises

Exercise 7.1 — Enhanced Photo Viewer

  • Build a photo viewer with OpenFileDialog supporting JPG, PNG, BMP, GIF, WEBP
  • Display filename, pixel dimensions, and file size in Labels below the PictureBox
  • Add Zoom In (+24px), Zoom Out (−24px, min 100px), Rotate 90°, and Flip Horizontal buttons
  • Add a ComboBox to switch SizeMode live between Normal, Zoom, StretchImage, CenterImage
  • Copilot challenge: Ask Copilot to "add a Save As button that saves the image to a user-chosen PNG path"

Exercise 7.2 — Slideshow with Speed Control

  • Load 4 or more images into an array using OpenFileDialog on startup
  • Add Play, Pause, Prev, Next buttons and a slide counter label
  • Add a TrackBar (1–10 s) to control the auto-advance speed — update Timer.Interval on scroll
  • Add navigation dots below the PictureBox that highlight the current slide index
  • Copilot challenge: Ask Copilot to "add a crossfade effect between slides using two overlapping PictureBoxes"

Exercise 7.3 — Thumbnail Gallery

  • Use a FlowLayoutPanel to hold 80×80 thumbnail PictureBoxes (SizeMode = Zoom)
  • Load all images from a user-chosen folder using Directory.GetFiles()
  • When a thumbnail is clicked, show the full image in a large PictureBox on the right
  • Display the selected image's filename, dimensions, and file size in a StatusStrip
  • Copilot challenge: Ask Copilot to "add right-click context menu to thumbnails with Open, Delete, and Set as Wallpaper options"

Next: Lesson 8 — Data Types

Learn about Visual Basic 2026's built-in data types — Integer, Double, String, Boolean, Date, Decimal and more — and how to choose the right type for every situation.

Continue ❯

Related Resources


Featured Books

Visual Basic 2022 Made Easy

Visual Basic 2022 Made Easy

by Dr. Liew Voon Kiong

Complete coverage of PictureBox, OpenFileDialog, Timer, and image manipulation with step-by-step projects.

View on Amazon →
VB Programming With Code Examples

VB Programming With Code Examples

by Dr. Liew Voon Kiong

48 fully-explained VB.NET programs — includes complete photo viewer and slideshow applications with full source code.

View on Amazon →
